EEC&COC
Overall Dimensions (mm) 3080*1280*1730
Battery Type 72V 58Ah /72V 100Ah Lithium battery
Wheelbase (mm) 2010
Rear Track (mm) 1100
Curb Weight (kg) 319
Brake Type (Front/Rear) Front disc / Rear drum
Brake Operation Foot / Hand brake
Cargo Box Inner Size (mm) 1520*1120
Rated Max Load (kg) 800
Max Speed (km/h) 25
Range (km) 60–70
Tire Size Front (steel) 4.00-12 / Rear (steel) 4.00-12
Rear Axle Differential rear axle
Motor 1500W*70H
Controller 30G
